1. ISW horizontal pipeline centrifugal pump is used to transport clean water and other liquids with physical and chemical properties similar to clean water. It is suitable for industrial and urban water supply and drainage, pressurized water supply for high-rise buildings, garden sprinkler irrigation, fire pressurization, long-distance transmission, HVAC refrigeration cycle, bathroom and other cold and warm water cycle pressurization and equipment supporting, with the operating temperature of T ≤ 80 ℃.

2. ISWR horizontal hot water pump is widely applicable to the pressurized circulating transmission of hot water from boilers in metallurgy, chemical industry, textile, paper making, hotels and restaurants and urban heating systems. The operating temperature of ALWR type is T ≤ 120 ℃.

3. ISWH horizontal chemical pump, free of solid particles, is corrosive. The liquid with viscosity similar to water is suitable for petroleum, chemical industry, metallurgy, electric power, paper making, food, pharmacy, synthetic fiber and other departments, and the operating temperature is - 20 ℃~+120 ℃.

4. ISWY horizontal pipeline oil pump is used to transport gasoline, kerosene, diesel and other oil products or flammable and explosive liquids. The temperature of the medium to be transported is - 20 ℃~120 ℃.

5. ISWHY horizontal stainless steel explosion-proof chemical centrifugal pump is suitable for conveying flammable chemical liquids.

6. ISWD horizontal low speed pump is suitable for occasions requiring low ambient noise, and the operating temperature is T ≤ 120 ℃.

1、 Product Overview

ISW, ISWR, ISWH, ISWD, ISWRD, ISWHD, ISWYD series horizontal single-stage single suction pipeline centrifugal pumps are designed according to the unique structural combination of IS type centrifugal pumps and vertical pumps, and are designed and manufactured in strict accordance with the international standard ISO2858 and the newer national pipeline centrifugal pump standard JB/T53058-93. The pump is optimized by domestic advanced hydraulic model. At the same time, hot water pump, high-temperature pump, chemical pump, oil pump, etc. are derived from ISW based on different operating temperatures, media, etc., which are the products approved and promoted by the current national standard.

2、 Model meaning

ISW100-160(I)AB

ISW horizontal centrifugal pump

100 - Diameter of pump inlet and outlet (mm)

160 - Nominal diameter of impeller (mm)

I-flow classification

AB - Impeller through * * *, secondary cutting

3、 Structural drawing

4、 Technical characteristics

Stable operation: the absolute concentricity of the pump shaft and the excellent dynamic and static balance of the impeller ensure stable operation without vibration.

No water leakage: cemented carbide seals of different materials ensure no leakage in transmission of different media.

Low noise: the water pump supported by two low-noise bearings runs smoothly, and there is basically no noise except for the faint sound of the motor.

Low failure rate: the structure is simple and reasonable, the key parts are matched with international * * * quality, and the trouble free working time of the whole machine is greatly improved.

Convenient maintenance: easy to replace seals and bearings.

More economical land occupation: the outlet can be left, right and upward, which is convenient for pipeline layout and installation and saves space.
