Product Overview

IS, IR, IH type horizontal single-stage single suction centrifugal pumps are used to pump clear water and liquids with similar physical and chemical properties and without solid particles. It is widely used in industry, agriculture, city, drainage, fire water supply, etc. The higher working temperature is 80 ° C, the allowable suction line pressure is 0.3MPa, and the higher operating pressure of the pump is 1.6MPa.

The pump is rear opening type. It is unnecessary to remove the suction and discharge pipes when removing the pump cover and impeller. The suspension is equipped with two ball bearings, which are lubricated with machine oil or grease. The pump is directly driven by the motor through the elastic coupling. The vortex chamber, foot, inlet flange and outlet flange are cast into a whole.
