Cold and hot clean, non flammable and explosive liquid without solid particles or fibers;

Liquid temperature: normal temperature type - 15 ℃~+70 ℃, hot water type+70 ℃+120 ℃

Ambient temperature:+40 ℃ for higher temperature;

Small inlet pressure: according to NPSH curve+0.5m water head with small safety head.

Product Overview

CDL light vertical multi-stage centrifugal pump is manufactured with Danish advanced technology. Its advantages are advanced hydraulic model design, high efficiency and high energy saving. The inner impeller, pump casing and its main accessories of the water pump are formed by stainless steel stamping. The flow passage is particularly smooth. The bearing bush and shaft sleeve are made of hard alloy, which has a strong service life and avoids secondary pollution. The shaft seal adopts wear-resistant mechanical seal, without leakage. The motor adopts Y2 lead shell, imported bearings, and the insulation grade is F. The pump operates stably, with low noise, reliable overall quality, beautiful appearance, small volume, light weight, convenient transportation and installation, and is an ideal green, environment-friendly and energy-saving pump.

Scope of application

Common type is suitable for liquid transmission, circulation and pressurization of hot and cold clean water and softened water.

The stainless steel type is also suitable for slightly alkaline water, demineralized water, distilled water, swimming pool water and its chloride containing liquid, but the allowable temperature of the liquid needs to be reduced.
