Product Overview

Single screw pump is a new type of pump based on rotary engagement volumetric principle. Its main working components are eccentric screw (rotor) and fixed bushing (stator).

Due to the special geometric shape of the two components, they are respectively opened into separate sealed chambers. The medium flows uniformly from the axial direction. The internal flow rate is low, the volume remains unchanged, and the pressure is stable. Because the surface will not produce eddy currents and agitation. The output pressure of each stage pump is 0.6MPa, the lift is 60m (clean water), and the self-priming height is generally 6m, which is suitable for conveying medium temperature below 80C (special requirements can reach 150 ° C).

Since the stator is made of a variety of elastic materials, this pump is competent for the transportation of high viscosity fluid and medium containing hard suspended particles or fiber medium, and its flow is proportional to the speed.

The transmission can be directly driven by coupling, or speed regulating motor, V-belt, gearbox and other devices can be used for speed change.

The pump has few parts, compact structure, small volume and simple maintenance. The rotor and stator are wearing parts of the pump, simple structure and easy assembly.
