Product Overview

SG series pipeline pump is a new type of vertical single-stage centrifugal pump developed to boost water delivery for high-rise buildings and solve the problem of low pipeline pressure. It has great advantages over the horizontal centrifugal pump currently used. Because of the advanced mechanical seal, the main shaft of the motor is directly installed with the impeller, so it has the characteristics of less leakage, high efficiency, low power consumption, compact structure, small volume, light weight, convenient decoration, and can be used in series according to the needs of lift and flow. As a replacement product of conventional centrifugal pump, this pump has replaced a variety of old pumps. It has been widely used in various industries and has become a general trend.

purpose

SG ordinary type is suitable for pressurization of water supply for high-rise buildings, garden sprinkler irrigation, cooling tower water supply, long-distance water delivery, refrigeration washing, bathroom and other cold and warm water circulation pressurization. The operating temperature is below 80 ℃.

SGR hot water type is suitable for pressurized circulation of high-temperature hot water in greenhouse, boiler and other industries. The operating temperature is below 120 ℃.

SGP corrosion-resistant stainless steel pipe pump is used to transport corrosive media, which is applicable to the process flow of food, pharmaceutical, wine making, chemical and other industries. The operating temperature is below 100 ℃.

SGB explosion-proof type is applicable to the transportation of non corrosive flammable and explosive liquids of petroleum and chemical liquids. The operating temperature is below 80 ° C.

SGPB anti-corrosion explosion-proof type is applicable to the transportation of corrosive flammable and explosive liquids such as chemical and chemical liquids. The operating temperature is below 140 ° C.
